Dan Kubin

Dan Kubin Sidewinder 46er - Nickel x Nickel RCA

Dan Kubin Sidewinder 46er - Nickel x Nickel RCA

£850.00 GBP
£920.00 GBP £850.00 GBP
Sale Sold out

Dan Kubin's Newest Sidewinder, the V46er!

The 46er is a culmination of my versions 4-6 Sidewinders, remastered and enhanced to perfection. This machine features a very large stroke adjustment range that can suite single needle work, all the way up to the largest liners and mag shaders.
This machine is very strong off the tip with a great follow-through.  It's number one purpose is as a strong, precise, off the tip liner; though It has proven to be much more capable
Highlights:
  • High Polish Nickel Plated Finish 🔥
  • Wider springs for more durability.
  • Large, easy to turn, hardened steel stroke wheel. Pre-set stroke range and middle timing mark to prevent the machine from getting too far out of tune when experimenting.
  • Hardened alloy steel impact pin. Positioned towards the rear of the frame to help with noise
  • Large cam with precise timing mark. Allows for easier, and more precise impact alignment checks
  • Smooth, easy clamping tube vice.
  • Forward weight distribution for better ergonomics.
  • Beautiful brass armature bar, perfectly balanced for a strong, confident, and consistent hit.
  • Reliable Mabuchi motor. -because they run forever without losing consistency.
Specifications:
  • Weighs 6 oz
  • Recommended voltage range: 4 - 6.5 volts
  • Approximate stroke range: 2 - 4mm (keep in mind the stoke goes up more due to the springs.  The stroke of a Sidewinder cannot be compared to other rotaries as the hit is completely different)
  • Polarity: Positive up - spins motor clockwise - slaps harder, ideal for large grouping liners. Positive down - spins motor counterclockwise -slightly passive hit, ideal for shading and fine line

RCA Specifications:

  • RCA version is wired for the harder hit mode only using RCA connection
  • This RCA motor housing was designed around a Critical Universal battery pack, but fits with most battery packs I have tried, such as Musotoku, Ink Claw, and Papa.
  • This will also work good with a right-angle RCA cord.
  • Clip Cord option still works, it is just wired backwards (Positive Down for Harder Hit)
  • The position of the battery makes the machine’s balance point much more forward, like a pen.
  • NEW RCA / Clip cord version with straight up battery position

Made in the USA!

All DK Machines sold by Workhorse are engineered, designed, and tested by Dan, milled in his most trusted machine shop, then assembled by DK certified trained technicians at the Workhorse facility in Michigan. All Sidewinders go through rigorous QC checks and are all ran through our testing machine to lightly break in. One year warranty on all models. All current Sidewinders are serviced by Workhorse, some older models are serviced by Dan or one of his certified technicians found on his website.
